G.652 |
G.655 |
G.657 |
50/125μm |
62.5/125μm |
|
|
Attenuation (+20℃) |
@850nm |
- |
- |
- |
≤3.5B/km |
≤3.5B/km |
|
@1300nm |
- |
- |
- |
≤1.5B/km |
≤1.5B/km |
|
|
@1310nm |
≤0.40/km |
≤0.4/km |
≤0.3/km |
- |
- |
|
|
@1550nm |
≤0.30/km |
≤0.30/km |
≤0.25/km |
- |
- |
|
|
Bandwidth (Class A) |
@850 |
- |
- |
- |
≥500MHZ·km |
≥20MHZ·km |
|
@1300 |
- |
- |
- |
≥1000MHZ·km |
≥600MHZ·km |
|
|
Numerical Aperture |
- |
- |
- |
- |
0.200±0.015NA |
0.275±0.015NA |
|
Cable Cut-off Wavelength λcc |
- |
≤1260nm |
≤1480nm |
≤1260nm |
- |
- |
|
Fiber Count |
Cable Diameter (mm) |
Cable Weight(Kg/km) |
Tensile Strength |
Crush Resistance |
Bending Radius Static/Dynamic (mm) |
|
2 |
3.5×5.5 |
19 |
200/400 |
100/200 |
30D/15D |
|
4 |
4.0×6.0 |
26 |
200/400 |
100/200 |
30D/15D |
|
6 |
5.0×7.0 |
30 |
200/400 |
100/200 |
30D/15D |
|
8 |
6.0×9.0 |
32 |
200/400 |
100/200 |
30D/15D |
|
12 |
6.5×9.5 |
40 |
200/400 |
100/200 |
30D/15D |
